Through-hole_Shenzhen Sembo Electronics Co., Ltd.

Part NO.	DC Spark-over voltage	Minimum Insulation Resistance		Maximum Capacitance (1KHz-6Vmax)	Surge current capacity (8/20μs)
Part NO.	Vs(V)	Test Voltage(V)	I(MΩ) Rohm	C(pF)	(A)
GSE-141M	140	50	100	1	10KV ＞2000A
GSE-201M	200	100	100	1
GSE-251M	250	100	100	1
GSE-301M	300	100	100	1
GSE-401M	400	100	100	1
GSE-501M	500	250	100	1
GSE-601M	600	250	100	1
GSE-701M	700	500	100	1
GSE-102M	1000	500	100	1
GSE-132M	1300	500	100	1
GSE-152M	1500	500	100	1
GSE-202M	2000	500	100	1
GSE-252M	2500	500	100	1
GSE-302M	3000	500	100	1
GSE-362M	3600	500	100	1
GSE-452M	1500	500	100	1
