Transient voltage suppressor
SURFACE MOUNT-SMBJ(600W 5-440V)
SMB/DO-214AA
Dimensions in inches and miuimeters
|
|
SMBJ DEVICES
|
REVERSE STAND-LFF VOLTAGE VRWM(v)
|
BREAKDOWN VOLTAGE Min. @I VBR Min.(V)
|
BREAKDOWN VOLTAGE Max.@I VBR Max.(V)T
|
TEST CURRENT IT(mA)
|
MAXIMUM CLAMPING VOLTAGE @Ipp VC(V)
|
PEAK PULSE CURRENT Ipp(A)
|
REVERSE LEAKAGE @VRWM IR(uA)
|
|
SMBJ5.0CA/A
SMBJ6.0CA/A
SMBJ6.5CA/A
SMBJ7.0CA/A
|
5.0
6.0
6.5
7.0
|
6.40
6.67
7.22
7.78
|
7.25
7.67
8.30
8.95
|
10
10
10
1
|
9.2
10.3
11.2
12.0
|
65.3
58.3
53.6
50.0
|
800
800
500
200
|
|
SMBJ7.5CA/A
SMBJ8.0CA/A
SMBJ8.5CA/A
SMBJ9.0CA/A
|
7.5
8.0
8.5
9.0
|
8.33
8.89
9.44
10.00
|
9.58
10.23
10.82
11.50
|
1
1
1
1
|
12.9
13.6
14.4
15.4
|
46.6
46.6
44.2
41.7
|
100
50
20
10
|
|
SMBJ10CA/A
SMBJ11CA/A
SMBJ12CA/A
SMBJ13CA/A
|
10.0
11.0
12.0
13.0
|
11.10
12.20
13.30
14.40
|
12.80
14.00
15.30
16.50
|
1
1
1
1
|
17.0
18.2
19.9
21.5
|
39.0
33.0
30.2
28.0
|
5
5
5
5
|
|
SMBJ14CA/A
SMBJ15CA/A
SMBJ16CA/A
SMBJ17CA/A
|
14.0
15.0
16.0
17.0
|
15.60
16.70
17.80
18.90
|
17.90
19.20
20.50
21.70
|
1
1
1
1
|
23.2
24.4
26.0
27.6
|
25.9
24.6
23.1
21.8
|
5
5
5
5
|
|
SMBJ18CA/A
SMBJ20CA/A
SMBJ22CA/A
SMBJ24CA/A
|
18.0
20.0
22.0
24.0
|
20.00
22.20
24.40
26.70
|
23.30
25.50
28.00
30.70
|
1
1
1
1
|
29.2
32.4
35.3
38.9
|
20.6
18.6
16.9
15.5
|
5
5
5
5
|
|
SMBJ26CA/A
SMBJ28CA/A
SMBJ30CA/A
SMBJ33CA/A
|
26.0
28.0
30.0
33.0
|
28.90
31.10
33.30
36.70
|
33.20
35.80
38.30
42.20
|
1
1
1
1
|
42.1
45.4
48.4
53.5
|
14.3
13.3
12.4
11.3
|
5
5
5
5
|
|
SMBJ36CA/A
SMBJ40CA/A
SMBJ43CA/A
SMBJ45CA/A
|
36.0
40.0
43.0
45.0
|
40.00
44.40
47.80
50.00
|
46.00
51.10
54.90
57.50
|
1
1
1
1
|
58.1
64.5
69.4
72.7
|
10.4
9.3
8.7
8.3
|
5
5
5
5
|
|
SMBJ48CA/A
SMBJ51CA/A
SMBJ54CA/A
SMBJ58CA/A
|
48.0
51.0
54.0
58.0
|
53.30
56.70
60.00
64.40
|
61.30
65.20
69.00
74.10
|
1
1
1
1
|
77.4
82.4
87.1
93.6
|
7.8
7.3
6.9
6.5
|
5
5
5
5
|
|
SMBJ60CA/A
SMBJ64CA/A
SMBJ70CA/A
SMBJ75CA/A
|
60.0
64.0
70.0
75.0
|
66.70
71.10
77.80
83.30
|
76.70
81.80
89.50
95.80
|
1
1
1
1
|
96.8
103.0
113.0
121.0
|
6.2
5.9
5.3
5.0
|
5
5
5
5
|
|
SMBJ78CA/A
SMBJ85CA/A
SMBJ90CA/A
SMBJ100CA/A
|
78.0
85.0
90.0
100.0
|
86.70
94.40
100.00
111.00
|
99.70
108.20
115.50
128.00
|
1
1
1
1
|
126.0
137.0
146.0
162.0
|
4.8
4.4
4.1
3.7
|
5
5
5
5
|
|
SMBJ110CA/A
SMBJ120CA/A
SMBJ130CA/A
SMBJ150CA/A
|
110.0
120.0
130.0
150.0
|
122.00
133.00
144.00
167.00
|
140.50
153.00
165.50
192.50
|
1
1
1
1
|
177.0
193.0
209.0
243.0
|
3.4
3.1
2.9
2.5
|
5
5
5
5
|
|
SMBJ160CA/A SMBJ170CA/A
SMBJ180CA/A
SMBJ200CA/A
|
160.0
170.0
180.0
200.0
|
178.00
189.00
201.00
224.00
|
205.00
217.50
230.40
256.00
|
1
1
1
1
|
259.0
275.0
292.0
324.0
|
2.3
2.2
2.1
1.9
|
5
5
5
5
|
|
SMBJ220CA/A
SMBJ250CA/A
SMBJ300CA/A
SMBJ350CA/A
|
220.0
250.0
300.0
350.0
|
246.00
279.00
335.00
391.00
|
281.60
309.00
371.00
432.00
|
1
1
1
1
|
356.0
405.0
486.0
567.0
|
1.7
1.5
1.3
1.1
|
5
5
5
5
|
|
SMBJ400CA/A
SMBJ440CA/A
|
400.0
440.0
|
447.00
492.00
|
494.00
543.00
|
1
1
|
648.0
713.0
|
0.9
0.9
|
5
5
|
