SMAJ DEVICES
|
REVERSE STAND-LFF VOLTAGE VRWM(v)
|
BREAKDOWN VOLTAGE Min.@IT VBR Min.(V)
|
BREAKDOWN VOLTAGE Max.@IT VBR Max.(V)
|
TEST CURRENT IT(mA)
|
MAXIMUM CLAMPING VOLTAGE @Ipp VC(V)
|
PEAK PULSE CURRENT Ipp(A)
|
REVERSE LEAKAGE @VRWM IR(uA)
|
|
SMCJ5.0CA/A
SMCJ6.0CA/A
SMCJ6.5CA/A
SMCJ7.0CA/A
|
5.0
6.0
6.5
7.0
|
6.40
6.67
7.22
7.78
|
7.00
7.37
7.98
8.60
|
10
10
10
1
|
9.2
10.3
11.2
12.0
|
163.0
145.7
134.0
125.0
|
800
800
500
200
|
|
SMCJ7.5CA/A
SMCJ8.0CA/A
SMCJ8.5CA/A
SMCJ9.0CA/A
|
7.5
8.0
8.5
9.0
|
8.33
8.89
9.44
10.00
|
9.21
9.83
10.40
11.10
|
1
1
1
1
|
12.9
13.6
14.4
15.4
|
116.3
110.3
104.2
97.4
|
100
50
20
10
|
|
SMCJ10CA/A
SMCJ11CA/A
SMCJ12CA/A
SMCJ13CA/A
|
10.0
11.0
12.0
13.0
|
11.10
12.20
13.30
14.40
|
12.30
13.50
14.70
15.90
|
1
1
1
1
|
17.0
18.2
19.9
21.5
|
88.3
82.5
75.4
69.8
|
5
5
5
5
|
|
SMCJ14CA/A
SMCJ15CA/A
SMCJ16CA/A
SMCJ17CA/A
|
14.0
15.0
16.0
17.0
|
15.60
16.70
17.80
18.90
|
17.20
18.50
19.70
20.90
|
1
1
1
1
|
23.2
24.4
26.0
27.6
|
64.7
61.5
57.7
54.4
|
5
5
5
5
|
|
SMCJ18CA/A
SMCJ20CA/A
SMCJ22CA/A
SMCJ24CA/A
|
18.0
20.0
22.0
24.0
|
20.00
22.20
24.40
26.70
|
22.10
24.50
26.90
29.50
|
1
1
1
1
|
29.2
32.4
35.5
38.9
|
51.4
46.3
42.3
38.6
|
5
5
5
5
|
|
SMCJ26CA/A
SMCJ28CA/A
SMCJ30CA/A
SMCJ33CA/A
|
26.0
28.0
30.0
33.0
|
28.90
31.10
33.30
36.70
|
31.90
34.40
36.80
40.60
|
1
1
1
1
|
42.1
45.4
48.4
53.3
|
35.7
33.1
31.0
28.2
|
5
5
5
5
|
|
SMCJ36CA/A
SMCJ40CA/A
SMCJ43CA/A
SMCJ45CA/A
|
36.0
40.0
43.0
45.0
|
40.00
44.40
47.80
50.00
|
44.20
49.10
52.80
55.30
|
1
1
1
1
|
58.1
64.5
69.4
72.7
|
25.9
23.3
21.7
20.6
|
5
5
5
5
|
|
SMCJ48CA/A
SMCJ51CA/A
SMCJ54CA/A
SMCJ58CA/A
|
48.0
51.0
54.0
58.0
|
53.30
56.70
60.00
64.40
|
58.90
62.70
66.30
71.20
|
1
1
1
1
|
77.4
82.4
87.1
93.6
|
19.4
18.2
17.3
16.1
|
5
5
5
5
|
|
SMCJ60CA/A
SMCJ64CA/A
SMCJ70CA/A
SMCJ75CA/A
|
60.0
64.0
70.0
75.0
|
66.70
71.10
77.80
83.30
|
73.70
78.60
86.00
92.10
|
1
1
1
1
|
96.8
103.0
113.0
121.0
|
15.5
14.6
13.3
12.4
|
5
5
5
5
|
|
SMCJ78CA/A
SMCJ85CA/A
SMCJ90CA/A
SMCJ100CA/A
|
78.0
85.0
90.0
100.0
|
86.70
94.40
100.00
111.00
|
95.80
104.00
111.00
123.00
|
1
1
1
1
|
126.0
137.0
146.0
162.0
|
11.9
11.0
10.3
9.3
|
5
5
5
5
|
|
SMCJ110CA/A
SMCJ120CA/A
SMCJ130CA/A
SMCJ150CA/A
|
110.0
120.0
130.0
150.0
|
122.00
133.00
144.00
167.00
|
135.00
147.00
159.00
185.00
|
1
1
1
1
|
177.0
193.0
209.0
243.0
|
8.5
7.8
7.2
6.2
|
5
5
5
5
|
|
SMCJ160CA/A
SMCJ170CA/A
|
160.0
170.0
|
178.00
189.00
|
197.00
209.00
|
1
1
|
259.0
275.0
|
5.8
5.5
|
5
5
|
