SA DEVICES
|
REVERSE STAND-LFF VOLTAGE VRWM(v)
|
BREAKDOWN VOLTAGE Min.@IT VBR Min.(V)
|
BREAKDOWN VOLTAGE Max.@IT VBR Max.(V)
|
TEST CURRENT IT(mA)
|
MAXIMUM CLAMPING VOLTAGE @Ipp VC(V)
|
PEAK PULSE CURRENT Ipp(A)
|
REVERSE LEAKAGE @VRWM IR(uA)
|
|
SA5.0CA/A
SA6.0CA/A
SA6.5CA/A
SA7.0CA/A
|
5.00
6.00
6.50
7.00
|
6.40
6.67
7.22
7.78
|
7.25
7.67
8.30
8.95
|
10
10
10
10
|
9.2
10.3
11.2
12.0
|
55.4
49.5
45.5
42.5
|
1000
500
200
50
|
|
SA7.5CA/A
SA8.0CA/A
SA8.5CA/A
SA9.0CA/A
|
7.50
8.00
8.50
9.00
|
8.33
8.89
9.44
10.00
|
9.58
10.23
10.82
11.50
|
1
1
1
1
|
12.9
13.6
14.4
15.4
|
39.5
37.5
35.4
33.1
|
10
5
5
5
|
|
SA10CA/A
SA11CA/A
SA12CA/A
SA13CA/A
|
10.00
11.00
12.00
13.00
|
11.10
12.20
13.30
14.40
|
12.80
14.00
15.30
16.50
|
1
1
1
1
|
17.0
18.2
19.9
21.5
|
30.0
28.0
25.6
23.7
|
3
3
3
3
|
|
SA14CA/A
SA15CA/A
SA16CA/A
SA17CA/A
|
14.00
15.00
16.00
17.00
|
15.60
16.70
17.80
18.90
|
17.90
19.20
20.50
21.70
|
1
1
1
1
|
23.2
24.4
26.0
27.6
|
22.0
20.9
19.6
18.5
|
3
3
3
3
|
|
SA18CA/A
SA20CA/A
SA22CA/A
SA24CA/A
|
18.00
20.00
22.00
24.00
|
20.00
22.20
24.40
26.70
|
23.30
25.50
28.00
30.70
|
1
1
1
1
|
29.2
32.4
35.5
38.9
|
17.5
15.7
14.4
13.1
|
3
3
3
3
|
|
SA26CA/A
SA28CA/A
SA30CA/A
SA33CA/A
|
26.00
28.00
30.00
33.00
|
28.90
31.10
33.30
36.70
|
33.20
35.80
38.30
42.20
|
1
1
1
1
|
42.1
45.4
48.4
53.3
|
12.1
11.2
10.5
9.6
|
3
3
3
3
|
|
SA36CA/A
SA40CA/A
SA43CA/A
SA45CA/A
|
36.00
40.00
43.00
45.00
|
40.00
44.40
47.80
50.00
|
46.00
51.10
54.90
57.50
|
1
1
1
1
|
58.1
64.5
69.4
72.7
|
8.8
7.9
7.3
7.0
|
3
3
3
3
|
|
SA48CA/A
SA51CA/A
SA54CA/A
SA58CA/A
|
48.00
51.00
54.00
58.00
|
53.30
56.70
60.00
64.40
|
61.30
65.20
69.00
74.10
|
1
1
1
1
|
77.4
82.4
87.1
93.6
|
6.6
6.2
5.9
5.4
|
3
3
3
3
|
|
SA60CA/A
SA64CA/A
SA70CA/A
SA75CA/A
|
60.00
64.00
70.00
75.00
|
66.70
71.10
77.80
83.30
|
76.70
81.80
89.50
95.80
|
1
1
1
1
|
96.8
103.0
113.0
121.0
|
5.3
5.0
4.5
4.2
|
3
3
3
3
|
|
SA78CA/A
SA85CA/A
SA90CA/A
SA100CA/A
|
78.00
85.00
90.00
100.00
|
86.70
94.40
100.00
111.00
|
99.70
108.20
115.50
128.00
|
1
1
1
1
|
126.0
137.0
146.0
162.0
|
4.0
3.7
3.5
3.1
|
3
3
3
3
|
|
SA110CA/A
SA120CA/A
SA130CA/A
SA150CA/A
|
110.00
120.00
130.00
150.00
|
122.00
133.00
144.00
167.00
|
140.50
153.00
165.50
192.50
|
1
1
1
1
|
177.0
193.0
209.0
243.0
|
2.9
2.6
2.4
2.1
|
3
3
3
3
|
|
SA160CA/A
SA170CA/A
SA180CA/A
|
160.00
170.00
180.00
|
178.00
189.00
200.00
|
205.00
217.50
230.40
|
1
1
1
|
259.00
275.00
289.00
|
2.0
1.9
1.7
|
3
3
3
|
Through-hole
