1.5KE DEVICES
|
REVERSE STAND-LFF VOLTAGE VRWM(v)
|
BREAKDOWN VOLTAGE Min.@IT VBR Min.(V)
|
BREAKDOWN VOLTAGE Max.@IT VBR Max.(V)
|
TEST CURRENT IT(mA)
|
MAXIMUM CLAMPING VOLTAGE @Ipp VC(V)
|
PEAK PULSE CURRENT Ipp(A)
|
REVERSE LEAKAGE @VRWM IR(uA)
|
|
1.5KE6.8CA/A
1.5KE7.5CA/A
1.5KE8.2CA/A
1.5KE9.1CA/A
|
5.80
6.40
7.02
7.78
|
6.45
7.13
7.79
8.65
|
7.14
7.88
8.61
9.55
|
10
10
10
1
|
10.5
11.3
12.1
13.4
|
144.8
134.5
125.6
113.4
|
1000
500
200
50
|
|
1.5KE10CA/A
1.5KE11CA/A
1.5KE12CA/A
1.5KE13CA/A
|
8.55
9.40
10.20
11.10
|
9.50
10.50
11.40
12.40
|
10.50
11.60
12.60
13.70
|
1
1
1
1
|
14.5
15.6
16.7
18.2
|
104.8
97.4
91.0
83.5
|
10
5
5
5
|
|
1.5KE15CA/A
1.5KE16CA/A
1.5KE18CA/A
1.5KE20CA/A
|
12.80
13.60
15.30
17.10
|
14.30
15.20
17.10
19.00
|
15.80
16.80
18.90
21.00
|
1
1
1
1
|
21.2
22.5
25.2
27.7
|
71.7
67.6
60.3
54.9
|
5
5
5
5
|
|
1.5KE22CA/A
1.5KE24CA/A
1.5KE27CA/A
1.5KE30CA/A
|
18.80
20.50
23.10
25.60
|
20.90
22.80
25.70
28.50
|
23.10
25.20
28.40
31.50
|
1
1
1
1
|
30.6
33.2
37.5
41.4
|
49.7
45.8
40.5
36.7
|
5
5
5
5
|
|
1.5KE33CA/A
1.5KE36CA/A
1.5KE39CA/A
1.5KE43CA/A
|
28.20
30.80
33.30
36.80
|
31.40
34.20
37.10
40.90
|
34.70
37.80
41.00
45.20
|
1
1
1
1
|
45.7
49.9
53.9
59.3
|
33.3
30.5
28.2
25.6
|
5
5
5
5
|
|
1.5KE47CA/A
1.5KE51CA/A
1.5KE56CA/A
1.5KE62CA/A
|
40.20
43.60
47.80
53.00
|
44.70
48.50
53.20
58.90
|
49.40
53.60
58.80
65.10
|
1
1
1
1
|
64.8
70.1
77.0
85.0
|
23.5
21.7
19.7
17.9
|
5
5
5
5
|
|
1.5KE68CA/A
1.5KE75CA/A
1.5KE82CA/A
1.5KE91CA/A
|
58.10
64.10
70.10
77.80
|
64.60
71.30
77.90
86.50
|
71.40
78.80
86.10
95.50
|
1
1
1
1
|
92.0
103.0
113.0
125.0
|
16.5
14.8
13.5
12.2
|
5
5
5
5
|
|
1.5KE100CA/A
1.5KE110CA/A
1.5KE120CA/A
1.5KE130CA/A
|
85.50
94.00
102.00
111.00
|
95.00
105.00
114.00
124.00
|
105.00
116.00
126.00
137.00
|
1
1
1
1
|
137.0
152.0
165.0
179.0
|
11.1
10.0
9.2
8.5
|
5
5
5
5
|
|
1.5KE150CA/A
1.5KE160CA/A
1.5KE170CA/A
1.5KE180CA/A
|
128.00
136.00
145.00
154.00
|
143.00
152.00
162.00
171.00
|
158.00
168.00
179.00
189.00
|
1
1
1
1
|
207.0
219.0
234.0
246.0
|
7.3
6.9
6.5
6.2
|
5
5
5
5
|
|
1.5KE200CA/A
1.5KE220CA/A
1.5KE250CA/A
1.5KE300CA/A
|
171.00
185.00
214.00
256.00
|
190.00
209.00
237.00
285.00
|
210.00
231.00
263.00
315.00
|
1
1
1
1
|
274.0
328.0
344.0
414.0
|
5.5
4.6
4.4
3.7
|
5
5
5
5
|
|
1.5KE350CA/A
1.5KE400CA/A
1.5KE440CA/A
1.5KE480CA/A
|
300.00
342.00
376.00
408.0
|
332.00
380.00
418.00
456.0
|
368.00
420.00
462.00
504.0
|
1
1
1
1
|
482.0
548.0
602.0
658.0
|
3.2
2.8
2.5
2.3
|
5
5
5
5
|
|
1.5KE510CA/A
1.5KE530CA/A
1.5KE540CA/A
1.5KE550CA/A
|
434.0
453.0
459.0
467.0
|
485.0
503.0
513.0
522.5
|
535.0
556.5
567.0
577.5
|
1
1
1
1
|
698.0
725.0
740.0
760.0
|
2.1
2.1
2.0
2.0
|
5
5
5
|
Through-hole
