| Part Number |
Maximum allowable voltage |
Varistor voltage |
Clamping voltage |
Maximum peak current |
Maximum peak current |
Rated power |
Typical capacitance (Reference) |
| Φ20.0mm |
(Max.) |
(8/20μs) |
(8/20μs) |
Standard
|
High surge
|
AC.rms |
DC |
V1.0mA |
VC |
IP |
Standard |
High surge |
Standard |
High surge |
（W） |
@1KHz(pf) |
| (V) |
(V) |
(V) |
(V) |
(A) |
（A） |
（A） |
（J） |
（J） |
| 20D180L |
J |
11 |
14 |
18(15-21) |
36 |
20
|
2000
|
3000
|
11 |
13 |
0.2 |
28500 |
| 20D220K |
J |
14 |
18 |
22(20-24) |
43 |
14 |
16 |
18500 |
| 20D270K |
J |
17 |
22 |
27(24-30) |
53 |
16 |
19 |
13000 |
| 20D330K |
J |
20 |
26 |
33(30-36) |
65 |
23 |
24 |
11500 |
| 20D390K |
J |
25 |
31 |
39(35-43) |
77 |
26 |
28 |
8500 |
| 20D470K |
J |
30 |
38 |
47(42-52) |
93 |
30 |
34 |
7400 |
| 20D560K |
J |
35 |
45 |
56(50-62) |
110 |
41 |
41 |
6500 |
| 20D680K |
J |
40 |
56 |
68(61-75) |
135 |
46 |
49 |
5800 |
| 20D820K |
J |
50 |
65 |
82(74-90) |
135 |
100 |
6500 |
10000 |
38 |
56 |
1 |
4900 |
| 20D101K |
J |
60 |
85 |
100(90-110) |
165 |
45 |
70 |
4000 |
| 20D121K |
J |
75 |
100 |
120(108-132) |
200 |
55 |
85 |
3300 |
| 20D151K |
J |
95 |
125 |
150(135-165) |
250 |
70 |
106 |
2700 |
| 20D181K |
J |
115 |
150 |
180(162-198) |
300 |
85 |
130 |
2200 |
| 20D201K |
J |
130 |
170 |
200(185-225) |
340 |
95 |
140 |
2000 |
| 20D221K |
J |
140 |
180 |
220(198-242) |
360 |
100 |
155 |
1800 |
| 20D241K |
J |
150 |
200 |
240(216-264) |
395 |
108 |
168 |
1650 |
| 20D271K |
J |
175 |
225 |
270(243-297) |
455 |
127 |
190 |
1500 |
| 20D301K |
J |
190 |
250 |
300(270-330) |
500 |
136 |
210 |
1300 |
| 20D331K |
J |
210 |
275 |
330(297-363) |
550 |
150 |
228 |
1200 |
| 20D361K |
J |
230 |
300 |
360(324-396) |
595 |
163 |
255 |
1100 |
| 20D391K |
J |
250 |
320 |
390(351-429) |
650 |
180 |
275 |
1000 |
| 20D431K |
J |
275 |
350 |
430(387-473) |
710 |
190 |
305 |
930 |
| 20D471K |
J |
300 |
385 |
470(426-517) |
775 |
220 |
350 |
850 |
| 20D511K |
J |
320 |
415 |
510(459-561) |
845 |
220 |
360 |
780 |
| 20D561K |
J |
350 |
460 |
560(504-616) |
925 |
220 |
380 |
710 |
| 20D621K |
J |
385 |
505 |
620(558-682) |
1025 |
220 |
390 |
650 |
| 20D681K |
J |
420 |
560 |
680(612-748) |
1120 |
230 |
400 |
600 |
| 20D751K |
J |
460 |
615 |
750(675-825) |
1240 |
255 |
420 |
530 |
| 20D781K |
J |
485 |
640 |
780(702-858) |
1290 |
265 |
440 |
510 |
| 20D821K |
J |
510 |
670 |
820(738-902) |
1355 |
282 |
460 |
500 |
| 20D911K |
J |
550 |
745 |
910(819-1001) |
1500 |
310 |
510 |
440 |
| 20D102K |
J |
625 |
825 |
1000(900-1100) |
1650 |
342 |
565 |
400 |
| 20D112K |
J |
680 |
895 |
1100(990-1210) |
1815 |
383 |
620 |
360 |
| 20D122K |
J |
700 |
990 |
1200(1080-1320) |
1880 |
408 |
660 |
320 |
| 20D182K |
J |
1100 |
1465 |
1800(1620-1980) |
2970 |
625 |
660 |
320 |
|
