 插件 |
|
|
| 14D系列 |
| Varistor Voltage: 18~1800V
Withstanding Surge Current: 1000~6000A
Model Size: 14mm
Fast responding to transient over-voltage<25ns
|
|
| |
| 产品详细说明 : |
| Part Number |
Maximum allowable voltage |
Varistor voltage |
Clamping voltage |
Maximum peak current |
Maximum peak current |
Rated power |
Typical capacitance (Reference) |
| Φ14.0mm |
(Max.) |
(8/20μs) |
(8/20μs) |
| Standard |
High surge |
AC.rms |
DC |
V1.0mA |
VC |
IP |
Standard |
High surge |
Standard |
High surge |
（W） |
@1KHz(pf) |
| (V) |
(V) |
(V) |
(V) |
(A) |
（A） |
（A） |
（J） |
（J） |
| 14D180L |
J |
11 |
14 |
18(15-21) |
36 |
10 |
1000 |
2000 |
4 |
7 |
0.1
|
11100 |
| 14D220K |
J |
14 |
18 |
22(20-24) |
43 |
5 |
8 |
9100 |
| 14D270K |
J |
17 |
22 |
27(24-30) |
53 |
6 |
10 |
7400 |
| 14D330K |
J |
20 |
26 |
33(30-36) |
65 |
7.5 |
12 |
6100 |
| 14D390K |
J |
25 |
31 |
39(35-43) |
77 |
8.6 |
13 |
5100 |
| 14D470K |
J |
30 |
38 |
47(42-52) |
93 |
10 |
17 |
4300 |
| 14D560K |
J |
35 |
45 |
56(50-62) |
110 |
11 |
20 |
3600 |
| 14D680K |
J |
40 |
56 |
68(61-75) |
135 |
14 |
24 |
2900 |
| 14D820K |
J |
50 |
65 |
82(74-90) |
135 |
50
|
4500
|
6000
|
22 |
27 |
2400 |
| 14D101K |
J |
60 |
85 |
100(90-110) |
165 |
28 |
33 |
0.6
|
2000 |
| 14D121K |
J |
75 |
100 |
120(108-132) |
200 |
32 |
40 |
1700 |
| 14D151K |
J |
95 |
125 |
150(135-165) |
250 |
40 |
53 |
1300 |
| 14D181K |
J |
115 |
150 |
180(162-198) |
300 |
50 |
60 |
1100 |
| 14D201K |
J |
130 |
170 |
200(185-225) |
340 |
57 |
70 |
1000 |
| 14D221K |
J |
140 |
180 |
220(198-242) |
360 |
60 |
78 |
900 |
| 14D241K |
J |
150 |
200 |
240(216-264) |
395 |
63 |
84 |
830 |
| 14D271K |
J |
175 |
225 |
270(243-297) |
455 |
70 |
99 |
740 |
| 14D301K |
J |
190 |
250 |
300(270-330) |
500 |
77 |
108 |
670 |
| 14D331K |
J |
210 |
275 |
330(297-363) |
550 |
85 |
115 |
610 |
| 14D361K |
J |
230 |
300 |
360(324-396) |
595 |
93 |
130 |
560 |
| 14D391K |
J |
250 |
320 |
390(351-429) |
650 |
100 |
140 |
510 |
| 14D431K |
J |
275 |
350 |
430(387-473) |
710 |
115 |
155 |
460 |
| 14D471K |
J |
300 |
385 |
470(426-517) |
775 |
125 |
175 |
430 |
| 14D511K |
J |
320 |
415 |
510(459-561) |
845 |
125 |
180 |
390 |
| 14D561K |
J |
350 |
460 |
560(504-616) |
925 |
125 |
185 |
360 |
| 14D621K |
J |
385 |
505 |
620(558-682) |
1025 |
125 |
190 |
320 |
| 14D681K |
J |
420 |
560 |
680(612-748) |
1120 |
130 |
200 |
290 |
| 14D751K |
J |
460 |
615 |
750(675-825) |
1240 |
143 |
210 |
270 |
| 14D781K |
J |
485 |
640 |
780(702-858) |
1290 |
148 |
220 |
260 |
| 14D821K |
J |
510 |
670 |
820(738-902) |
1355 |
157 |
235 |
240 |
| 14D911K |
J |
550 |
745 |
910(819-1001) |
1500 |
175 |
255 |
220 |
| 14D102K |
J |
625 |
825 |
1000(900-1100) |
1650 |
190 |
280 |
200 |
| 14D112K |
J |
680 |
895 |
1100(990-1210) |
1815 |
213 |
310 |
180 |
| 14D122K |
J |
700 |
990 |
1200(1080-1320) |
1880 |
213 |
310 |
150 |
| 14D182K |
J |
1100 |
1465 |
1800(1620-1980) |
2970 |
5000 |
250 |
335 |
130 |
|
|
|
|
